Onkyo TX-NR709 7.2Ch THX Network AV Receiver (Sold)
Onkyo TX-NR709 7.2CH THX Network AV Receiver Used In Excellent Condition. Now Selling At RM1,650. Free Shipping Within West Malaysia.
Please visit www.stylelaser.com.my to find out more products for sale at very special price...
With its bountiful array of connections, the TX-NR709 A/V receiver handles just about any playback device you care to hook up. Eight HDMI® inputs give you plenty of scope for high-definition sources, while two HDMI outputs double your display options. HDMI supports pristine lossless audio from Dolby and DTS and video upscaling to stunning 4K resolution via Qdeo™ technology. Connectivity is further enhanced by a front-panel USB port for digital link-up of iPod/iPhone, and a wide range of analog and digital inputs—including S-Video and 7.1 analog multichannel inputs—for all your legacy components. The network-capable TX-NR709 also brings PC audio and internet radio to your living room, where Audyssey MultEQ® XT calibrates the soundfield to match the room’s unique dimensions. Onkyo’s graphical OSD and navigation GUI make it easy to browse your content and adjust settings on the fly. Finally, bi-amping capability, 7.2 multichannel pre-outs, and a dedicated phono input provide further flexibility for the demanding audiophile and help propel the TX-NR709 to the head of its class.
Key Features
· THX® Select2 Plus™ Certified
· HDMI® Support for 3D Video and Audio Return Channel
· Network Capability Delivers Internet Radio and Network Audio Streaming via Ethernet
· 4K Video Upscaling and Processing via Qdeo™ Technology
· Tailor Multichannel Audio to Your Home with Audyssey and Dolby Technologies
SPECIFICATIONS
Amplifier Section
Power Output
Front L/R 170 W/Ch
(6 Ω, 1 kHz, 1%, 1 channel driven, IEC)
Center 170 W
(6 Ω, 1 kHz, 1%, 1 channel driven, IEC)
Surround L/R 170 W/Ch
(6 Ω, 1 kHz, 1%, 1 channel driven, IEC)
Surround Back L/R, Front High L/R, Front Wide L/R, or Zone 2 L/R
170 W/Ch
(6 Ω, 1 kHz, 1%, 1 channel driven, IEC)
Dynamic Power 250 W (3 Ω, Front)
220 W (4 Ω, Front)
130 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (Line)
2.5 mV/47 kΩ (Phono MM)
Rated RCA Output Level and Impedance
200 mV/470 Ω (Pre out)
Maximum RCA Output Level and Impedance
4.6 V/470 Ω (Pre out)
Phono Overload 70 mV (MM, 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/+1 dB, -3 dB (Direct mode)
Tone Control ±10 dB, 50 Hz (Bass)
±10 dB, 20 kHz (Treble)
Signal-to-Noise Ratio 106 dB (Line, IHF-A)
80 dB (Phono MM, IHF-A)
Speaker Impedance 4 Ω–16 Ω or 6 Ω–16 Ω
Video Section
Input Sensitivity/Output Level and Impedance
Video 1.0 Vp–p/75 Ω (Component and S-Video
Y)
0.7 Vp–p/75 Ω (Component PB/CB, PR/CR)
0.25 Vp–p/75 Ω (S-Video C)
1.0 Vp–p/75 Ω (Composite)
Component Video Frequency Response
5 Hz–100 MHz/0 dB, -3 dB
Tuner Section
Tuning Frequency Range
FM 87.5 MHz–108 MHz
AM 522 kHz–1,611 kHz
530 kHz–1,710 kHz
FM/AM Preset Memory 40 stations
General
Power Supply AC 220–240 V~, 50/60 Hz
Power Consumption 570 W
Dimensions (W x H x D) 435 x 174 x 379 mm
Weight 12.2 kg
Interested please feel free to contact:
Peter 012-2536225
Fong 016-3098668
Business hour:
MONDAY - 10AM-7PM
TUESDAY - 10AM-7PM
WEDNESDAY - CLOSED(PASAR MALAM)
THURSDAY - 10AM-7PM
FRIDAY - 10AM-7PM
SATURDAY - 10AM-7PM
SUNDAY - 1PM-6PM
PUBLIC HOLIDAY - 1PM-6PM
Style Online Store 24Hous
location:
STYLE LASER AUDIO SDN BHD
No.148, Jalan Cerdas, Taman
Connaught, Cheras 56000 Kuala Lumpur
( NEXT TO ALLIANCE BANK )
We buy in your old items in CASH!!
Got something keep at home but seldom use or planning to upgrade?
Items that we buy:
BRANDED led tv
amplifier
speaker
cd player
Please Whatsapp the item photo to me and get the price immediately, once confirmed the deal, we will pick up your item from you and pay you in cash.
Thanks for viewing.
