Dynavector XX-2 MK2 (SOLD)

Go down

Dynavector XX-2 MK2 (SOLD) Empty Dynavector XX-2 MK2 (SOLD)

Post by tongho Thu May 18, 2023 6:35 pm

selling beloved Dynavector XX-2 Mk2 cartridge SOLD

https://wa.me/+60122738893

Dynavector XX-2 MK2 (SOLD) 211
Dynavector XX-2 MK2 (SOLD) 111
Dynavector XX-2 MK2 (SOLD) 311


The DV XX-1 was the first cartridge to feature a "magnetic flux damper" (patent) and softened magnetism" (patent) processes that reject the magnetic fluctuation that is detrimental to a moving coil cartridges performance.
The The DV XX-2 MKII retains the benefit of the flux damper but features the Alnico-5 magnet and the similar rigid construction to the Te Kaitora Rua. Alnico magnets exhibit high magnetic flux density combining with a low coercive therefore magnetic resistance is lower than other magnetic types such as rare earth and ferrite, providing the exceptional stability of the XX-2 MKII output voltage. There is also the additional advantage of low magnetic and electrical resistance contributing to a discernable improvement in sound quality.
The XX-2MKII also exhibits deep powerful bass, treble is both clear and lively possessing none of the hardness found in many moving coil designs.
The XX-2MKII also features a 6 mm solid boron cantilever fitted with a Pathfinder Line contact stylus. PCOCC (pure copper ohno continuous casting process) copper wire is used for the coil. The output voltage of 0.28mV is higher than that of the XX-2 and 6 ohms impedance are suited to most moving coil phono stages.
For ridgity of construction the XX-2 MKII cartridge body is machined from 7075 aluminium the hardest available. However, having only a total weight of only 8.9 grams it is suitable for a variety of popular tonearms.
























[size=14][b][size=12][b]Type[/b][/size][/b][/size][size=14][size=12]Low output moving coil cartridge with Alnico magnet and Flux damper[/size][/size]
[size=14][b][size=12][b]Output Voltage[/b][/size][/b][/size][size=14][size=12]0.28mV (at 1KHz, 5cm/sec.)[/size][/size]
[size=14][b][size=12][b]Channel Separation[/b][/size][/b][/size][size=14][size=12]30 dB (at 1KHz)[/size][/size]
[size=14][b][size=12][b]Channel balance[/b][/size][/b][/size][size=14][size=12]1.0 dB (at 1KHz)[/size][/size]
[size=14][b][size=12][b]Frequency response[/b][/size][/b][/size][size=14][size=12]20 - 20,000Hz (± 1dB)[/size][/size]
[size=14][b][size=12][b]Compliance[/b][/size][/b][/size][size=14][size=12]10 mm/N[/size][/size]
[size=14][b][size=12][b]Tracking force[/b][/size][/b][/size][size=14][size=12]1.8 - 2.2 g[/size][/size]
[size=14][b][size=12][b]Impedance[/b][/size][/b][/size][size=14][size=12]6 ohms[/size][/size]
[size=14][b][size=12][b]Recommended load impedance[/b][/size][/b][/size][size=14][size=12]> 30 ohms[/size][/size]
[size=14][b][size=12][b]Cantilever[/b][/size][/b][/size][size=14][size=12]6mm length 0.3 mm dia. solid boron[/size][/size]
[size=14][b][size=12][b]Stylus tip[/b][/size][/b][/size][size=14][size=12]PF Line contact shape, stylus radius: 7 x 30 micron[/size][/size]
[size=14][b][size=12][b]Weight[/b][/size][/b][/size][size=14][size=12]8.9 g[/size][/size]

tongho
Frequent Contributor
Frequent Contributor

Number of posts : 867
Age : 41
Location : KL
Registration date : 2014-03-04

Character sheet
Source(s): VPI Prime, Audia Flight Phono, SoulNote sc710
Amplification: Accuphase E470
Speakers: Quad z3
