Specifications
Power Rating: 100 watt RMS (250 watt peak)
Recommended Amplifier Power: 30 - 150 watt/channel
Sensitivity ( 2,83 V at 1 m): 93 dB
Maximum SPL: 113 dB at 1m for 100 watt RMS (117 dB at 1m for 250 watt peak)
Nominal Impedance: 8 Ω
Minimum Impedance: 5,5 Ω
Frequency Response: 35 Hz - 25 kHz , ±3 dB (port mid position)
Crossover Frequencies: 1,3 kHz
Crossover Control: ±3 dB over 1,3 kHz to 25 kHz shelving;
Crossover Type: 1st order LF; 1st order HF,
Bi-wired, hard-wired, passive, low-loss, time compensated Type 1134
Driver Type: 10-inch Dual Concentric High Compliance Type 2598
Enclosure Type: Dual variable distributet port system
Enclosure Volume: 68 litre
Dimensions (H x W x D): 700 x 486 x 310 mm; (850 x 525 x 380 mm packed)
Weight: 22 kg complete (27 kg packed)
Enclosure Material: Solid walnut with 18 mm particle board, crossbracing and heavy internal damping
